195W 12V Portable Solar Panel with Kyocera Cells (TRIFOLD)
Aussie Batteries and Solar easy to use 195W portable solar power, built with Japanese made Kyocera Multi-Crystalline Solar Cells. All wired up ready to go, just fold out, plug into your battery (via supplied Anderson plug connection) and you'll be charging in no time!
When you want quality, reliability and performance choose KYOCERA Solar Cells. Kyocera is respected worldwide for quality and long-term commitment to customer satisfaction. These panels are constructed with Japanese made Kyocera Multi-Crystalline solar cells that offer impressive features including:
1. Unique and pioneering multi-crystalline technology allows for virtually square-cut cells which provide for greater surface area to collect sunlight and increase output
2. Proprietary encapsulants to better seal components and prevent performance degradation
3. Proprietary etching and coating process provides for a uniform appearance, further increasing kWh yield and improving aesthetics
5. Kyocera's triple buss-bar design reduces resistance, providing a more efficient capture of the sun's energy which translates to greater module output
(100389)
- Max Power Current: 10.83A
- Waterproof 20A Solar Regulator (IP66 Rating)
- High Quality Hail Proof Panels
- Anodised Aluminum Stands & Frame (Rustproof)
- Pre Wired Nothing to Buy
- High Quality Kyocera unique and pioneering Multi-Crystalline Cells Technology
- Easy to use portable Solar Power System
- 25 year performance warranty - guaranteed 80% of rated solar power wattage
- 2 general warranty - repair or replacement warranty for construction or components
- Weight: appx 20.8kg
- Dimensions: Folded: 900mm x 584mm x 110mm
- Dimensions: Opened: 900mm x 1670mm x 35mm
Included:
- Folding Solar Panel - (Pre Wired and Ready To Go)
- Waterproof 20A Solar Regulator (IP66 Rating)
- 7m Heavy-Duty Cable With Anderson plug
- Operation Manual
| Max Power: | 195W |
| Power Tolerance: | -1%~+3% |
| Max Power Voltage: | 18V |
| Max Power Current: | 10.83A |
| Open-Circuit Voltage: | 22.03V |
| Short-Circuit Current: | 11.55A |
| Maximum System Voltage: | 1000 |
| Dimensions: | Folded: 900mm x 584mm x 110mm Opened: 900mm x 1670mm x 35mm |
| Weight: | Approx. 20.8kg |
| Test Condition: | 1000W/m2, AM1.5, 25°C |
Included:
- Folding Solar Panel - (Pre Wired and Ready To Go)
- Waterproof 20A Solar Regulator (IP66 Rating)
- 7m Heavy-Duty Cable With Anderson plug
- Operation Manual
| SKU | 100389 |
| Model # | PS-KYO-150W3 |
| Barcode # | 100389 |
| Brand | Aussie Bateries & Solar |
| Shipping Weight | 21.0000kg |
| Shipping Width | 0.140m |
| Shipping Height | 0.950m |
| Shipping Length | 0.540m |
| Shipping Cubic | 0.071820000m3 |
